MaxLink MAXPI60W2x2 PoE injector - 802.3af/at, 55V, 1.1A, 60W, 1Gbit, 2xLAN, 2XPoE

0/0

MaxLink MAXPI60W2x2 PoE injector - 802.3af/at, 55V, 1.1A, 60W, 1Gbit, 2xLAN, 2XPoE

MAXPI60W2x2

Where to buy

All variants

MaxLink MAXPI60W2x2 PoE injector - 802.3af/at, 55V, 1.1A, 60W, 1Gbit, 2xLAN, 2XPoEMAXPI60W2x2currently displayed productMaxLink PI60 2x2 is a dual-port PoE injector designed for indoor use. It provides 55 VDC power for remote PDs through one PoE port or delivers 30W per port for two remote PDs simultaneously.It powers...

compare send a question

Send a question

E-mail

Text

Send

Download1

Product description

MaxLink PI60 2x2 is a dual-port PoE injector designed for indoor use. It provides 55 VDC power for remote PDs through one PoE port or delivers 30W per port for two remote PDs simultaneously. It powers terminal devices that support the IEEE802.3af/at standard, such as wireless access points, base stations, high-power cameras, door locks, displays, POS terminals, information kiosks, and other high-power Ethernet terminals. It supports data transfer speeds of 10/100/1000 Mbps. The effective range is 100 meters over Cat5e/Cat6 cables.

Specifications

Connectors and Interfaces

Ethernet speed [Mb/s]:10/100/1000

Gigabit LAN:Yes

Power

Pin powering:1,2,7,8 (-), 3,4,5,6 (+)

Output Power / 1port [W]:60

PoE-Out standards:802.3af, 802.3at

PoE Out ports:2

Output Voltage [V]:55

Physical characteristics

LED indication:Yes

Operating temperature [°C]:-30 up to 55

Weight [g]:460

Depth [mm]:46

Width [mm]:85

Height [mm]:208

Download

Datasheet
