MaxLink 25G SFP28 optical module, MM, 100m, 2x LC konektor, DDM

ML-S28-MM-100
ML-S28-MM-100 is a multi-mode SFP28 module with a wavelength of 850nm, a speed of 25 Gbps, 2x LC connectors and a maximum distance of 100m. SFP module supports DDM - digital diagnostics monitoring.The LC connectors in the SFP module have UPC polishing.The module is compatible with all active elemen... More information

Product description

ML-S28-MM-100 is a multi-mode SFP28 module with a wavelength of 850nm, a speed of 25 Gbps, 2x LC connectors and a maximum distance of 100m. SFP module supports DDM - digital diagnostics monitoring.

The LC connectors in the SFP module have UPC polishing.

The module is compatible with all active elements from MikroTik and also with devices from other manufacturers "Cisco compatible".

Specifications

Optics

Format:SFP28
For cable type:Multi Mode
Transmission speed:25 Gbps
Wavelength - Tx/Rx [nm]:850
Distance [km]:0,1
Transfer type:2-fiber
Polishing type:UPC
Tx power [dBm]:-7 up to 2,4
Receiver sensitivity [dBm]:-10,3

Connectors and Interfaces

Optical Connectors:(2) LC

Physical characteristics

Operating temperature [°C]:0 up to 70

General

Compatibility:Universal

Software

DDMI - diagnostics:Yes
